產品名稱： | TYG系列高起動轉矩高效永磁同步電動機 | ||||
| 型號規格： |   放大圖片 |
|||||
| 產品類別： | 常規產品 -- 電機產品 -- 永磁同步電機 | |||||
| |
參考價格： | 廠價直銷 | ||||
| 產品品牌： | 國產 | |||||
| 產品產地： | 上海 | |||||
| |
可供數量： | 批量 | ||||
| 供貨周期： | 現貨(或電詢) | |||||
 |
|
|||||
| |
產品簡介： |
|
||||
TYG系列高起動轉矩高效永磁同步電動機的結構為封閉自扇冷式鼠籠型，防護等級為IP44，冷卻方式為IC411，安裝型式為IMB3，額定電壓為380V，頻率為50HZ，功率等級和安裝尺寸符合IEC標準的規定。
TYG系列電機采用了稀土永磁材料，因而具有高效率，高功率因數，高起動轉矩，噪聲小，溫升低等突出優點。可廣泛應用于油田游梁式抽油機和礦山機械等行業，具有良好的使用性能和顯著節能效果。
| 機座號 Frame NO. |
安裝尺寸Mounting Dimensions(mm) |
外形尺寸Outline Dimensions(mm) | ||||||||||||
|
A |
B |
C |
D |
E |
F |
G |
H |
K |
AB |
AC |
AD |
HD |
L | |
|
TYG132S |
216 |
140 |
89 |
38 |
80 |
10 |
33 |
132 |
12 |
270 |
275 |
210 |
345 |
470 |
|
TYG132M |
216 |
178 |
89 |
38 |
80 |
10 |
33 |
132 |
12 |
270 |
275 |
210 |
345 |
510 |
|
TYG160M |
254 |
210 |
108 |
42 |
110 |
12 |
37 |
160 |
14.5 |
320 |
330 |
255 |
420 |
615 |
|
TYG160L |
254 |
254 |
108 |
42 |
110 |
12 |
37 |
160 |
14.5 |
320 |
330 |
255 |
420 |
670 |
|
TYG180M |
279 |
241 |
121 |
48 |
110 |
14 |
42.5 |
180 |
14.5 |
355 |
380 |
280 |
455 |
700 |
|
TYG180L |
279 |
279 |
121 |
48 |
110 |
14 |
42.5 |
180 |
14.5 |
355 |
380 |
280 |
455 |
740 |
|
TYG200L |
318 |
305 |
133 |
55 |
110 |
16 |
49 |
200 |
18.5 |
395 |
420 |
305 |
505 |
770 |
|
TYG225S |
356 |
286 |
149 |
60 |
140 |
18 |
53 |
225 |
18.5 |
435 |
470 |
335 |
560 |
815 |
|
TYG225M |
356 |
311 |
149 |
60 |
140 |
18 |
53 |
225 |
18.5 |
435 |
470 |
335 |
560 |
845 |
|
TYG250M |
406 |
349 |
168 |
65 |
140 |
18 |
58 |
250 |
24 |
490 |
510 |
370 |
615 |
910 |
|
TYG280S |
457 |
368 |
206 |
75 |
140 |
20 |
67.5 |
280 |
24 |
550 |
580 |
410 |
680 |
985 |
|
TYG280M |
457 |
419 |
206 |
75 |
140 |
20 |
67.5 |
280 |
24 |
550 |
580 |
410 |
680 |
1035 |
|
型 號 Type |
額定功率 RatedP. (kW) |
額定電流 Rated C. (A) |
額定電壓 Voit (V) |
額定 |
效率 Eff.(%) |
功率因數 Power foctor |
堵轉轉矩 Locked Tor. |
堵轉電流 Locked C. |
最小轉矩 Min. Tor. | |||
|
負 載 率 Load Ratio |
額定轉矩 Rated Tor. |
額定電流 Rated C. |
額定轉矩 Rated Tor. | |||||||||
|
1.0 |
0.75 |
0.5 |
0.25 | |||||||||
|
TYG132S-4 |
5.5 |
9.5 |
380 |
1500 |
92.8 |
92.5 |
91.8 |
84.5 |
0.96-1.0 |
2.8 |
10.0 |
1.5 |
|
TYG132M-4 |
7.5 |
12.9 |
380 |
1500 |
93.5 |
93.2 |
92.5 |
84.5 |
2.8 |
10.0 |
1.5 | |
|
TYG132M-6 |
5.5 |
9.5 |
380 |
1000 |
93.0 |
92.5 |
91.0 |
83.0 |
2.8 |
9.0 |
1.5 | |
|
TYG160M-4 |
11 |
18.6 |
380 |
1500 |
94.5 |
94.2 |
92.5 |
85.0 |
2.8 |
10.0 |
1.7 | |
|
TYG160L-4 |
15 |
25.4 |
380 |
1500 |
94.8 |
94.5 |
93.5 |
86.0 |
2.8 |
10.0 |
1.7 | |
|
TYG160M-6 |
7.5 |
12.9 |
380 |
1000 |
93.2 |
92.8 |
91.2 |
83.5 |
2.8 |
9.0 |
1.7 | |
|
TYG160L-6 |
11 |
18.8 |
380 |
1000 |
93.5 |
93.2 |
91.5 |
84.5 |
2.8 |
9.0 |
1.7 | |
|
TYG160M-8 |
5.5 |
9.4 |
380 |
750 |
92.5 |
92.0 |
89.8 |
84.0 |
2.8 |
9.0 |
1.5 | |
|
TYG160L-8 |
7.5 |
12.8 |
380 |
750 |
93.0 |
82.2 |
91.0 |
82.5 |
2.8 |
9.0 |
1.5 | |
|
TYG180M-4 |
18.5 |
31.3 |
380 |
1500 |
94.8 |
94.5 |
93.5 |
86.0 |
2.8 |
10.0 |
1.7 | |
|
TYG180L-4 |
22 |
37.1 |
380 |
1500 |
95.0 |
94.8 |
93.5 |
86.0 |
2.8 |
10.0 |
1.7 | |
|
TYG180L-6 |
15 |
25.5 |
380 |
1000 |
94.0 |
93.5 |
92.0 |
85.0 |
2.8 |
9.0 |
1.7 | |
|
TYG180L-8 |
11 |
18.7 |
380 |
750 |
93.2 |
92.5 |
91.5 |
83.5 |
2.8 |
9.0 |
1.7 | |
|
TYG200L1-6 |
18.5 |
37.4 |
380 |
1000 |
94.2 |
93.8 |
92.5 |
85.0 |
2.8 |
9.0 |
1.7 | |
|
TYG200L2-6 |
22 |
37.2 |
380 |
1000 |
94.5 |
94.0 |
92.8 |
85.0 |
2.7 |
9.0 |
1.7 | |
|
TYG200L-8 |
15 |
25.4 |
380 |
750 |
93.5 |
93.0 |
92.0 |
84.0 |
2.7 |
9.0 |
1.7 | |
|
TYG225S-8 |
18.5 |
31.1 |
380 |
750 |
94.0 |
93.5 |
92.2 |
84.2 |
2.7 |
9.0 |
1.7 | |
|
TYG225M-8 |
22 |
37 |
380 |
750 |
94.0 |
93.5 |
92.2 |
84.2 |
2.7 |
9.0 |
1.7 | |
|
TYG250M1-6 |
30 |
50.6 |
380 |
1000 |
94.8 |
94.2 |
93.2 |
83.2 |
2.7 |
9.0 |
1.7 | |
|
TYG250M2-6 |
37 |
62.4 |
380 |
1000 |
94.8 |
94.2 |
93.2 |
83.2 |
2.7 |
9.0 |
1.8 | |
|
TYG250M-8 |
30 |
50.4 |
380 |
750 |
94.2 |
93.8 |
92.5 |
84.8 |
2.7 |
9.0 |
1.7 | |
|
TYG280S-6 |
45 |
75.8 |
380 |
1000 |
95.0 |
94.8 |
93.5 |
83.5 |
2.7 |
9.0 |
1.8 | |
|
TYG280S-8 |
37 |
62.2 |
380 |
750 |
94.2 |
94.0 |
92.8 |
85.2 |
2.7 |
9.0 |
1.8 | |
|
TYG280M-8 |
45 |
75.6 |
380 |
750 |
94.5 |
94.2 |
93.0 |
85.5 |
2.7 |
9.0 |
1.8 | |
|
TYG200L1-12 |
11 |
18.4 |
380 |
500 |
92.5 |
91.5 |
91.3 |
79.7 |
0.92-1.0 |
2.2 |
7 |
1.7 |
|
TYG200L2-12 |
15 |
25 |
380 |
500 |
93.1 |
91.8 |
92 |
81.3 |
2.2 |
7 |
1.7 | |
|
TYG250M-12 |
22 |
39.4 |
380 |
500 |
92.2 |
91 |
90 |
83 |
2.2 |
7 |
1.7 | |
|
TYG280M-16 |
22 |
36.4 |
380 |
500 |
92.3 |
91.4 |
88.3 |
76.5 |
2.2 |
9 |
1.7 | |
